led high bay lamps

Dimmable LED high bay

Product Description

5000-5500K Pure white LED High Bay Light

Specifications:

250W LED High Bay

Model No.	AMB-3L-250w
Equivalent	800W High Pressure Sodium Lamp
LED Light Source	3 × 70W Bridgelux 60mil LED
LED Luminous Efficiency	130 lm/w
Lamp Total Power	250W
Power Efficiency	> 95%
Lamp Rated Luminous Flux	> 24500lm
Lamp Rated Luminous Efficiency	> 95lm/W
Color Rendering Index(CRI)	Ra> 75
Color Temperature(Color Temperature)	Cool white: 6000-6500K
	Pure white: 5000-5500K
	Warm white: 2700-3200K
Beam Angle	60 /120 /135 /150 degrees
Dimension	Φ480×360-Φ580×572
Input Voltage	AC 85~305V, or AC347, or AC385
FrequencyRange	50/60HZ
Power Factor(PF)	> 0.95
Total Harmonic Distortion(THD)	< 15%
Storage Temperature	-40--+80
Working Environment	-40--+50; 10%-95%RH
Junction Temperature(Tj)	60 ± 10%(ta=25)
Light Body and Lampshade Material	Aluminum Alloy and AL glass
Working Lifetime	> 50, 000hrs
IP Rating	IP65

IP65 250W AC85~305V 5years Warranty LED High Bay Fixtures With HLG Model Meanwell Driver 60mil Bridgelux Chip

AMB, which only specialized in led high bay and led tube manufacturer in Shenzhen, China. AMB have cooperated with famous led lights component company, such as USA Bridgelux company, Taiwan Everlight company, Taiwan Meanwell ect. So that AMB can use the best components for our lights and provide the best quantity led high bay/led tube for AMB esteemed clients

1.Warranty: 3-5years warranty time, life-span is more than 50,000hrs, 50~300w.

2.Meanwell driver: which is top quality from TaiWan. It has UL, CE, TUV,PSE certificates.

3.Chip: Bridgelux 45mi C0B LED , it has 110-120lumens/w with 3years warranty time. 5years warranty time item is 130-145lumen/w with 60mil Bridgelux led chip.

4.Own cooling system: with our patent system, our LED's working temperature is only 50degrees when ambient temperature is 30-35degrees (for 150w).

5.Different beam angles: we have 60degrees, 120degrees, 135degrees and 150degrees, it fits our clients different tastes.

6.Traditional MHL Replacement: AMB 80W/100W led high bay replace 250w MHL, AMB 150W led high bay replace 400w NHL, AMB 250W/300W led high bay replace 1000W MHL.

No.

	1	2	3	4	5
Model No.	AMB-3L-50w	AMB-3L-80w	AMB-3L-100w	AMB-3L-120w	AMB-3L-150w
Power Consumptionb (W)	50	80	100	120	150
LED Initial Flux (LM)	5200	8300	12000	12500	14600
Lamp Flux (LM)	4800	7500	10400	11900	13500
Beam Angle	60°/ 120°/150°	60°/ 120°/150°	60°/120°/ 135°/150°	60°/120° /135°/150°	60°/120°/135°/150°
Input Voltage (VAC)	90-305	90-305	90-305	90-305	90-305
Power Factor (PF)	>0.97	>0.97	>0.97	>0.97	>0.97
Power Efficiency	96%	93%	104%	95.8%	92%
Color	Warm White Cool White	Warm White Cool White	Warm White Cool White	Warm White Cool White	Warm White Cool White
Color Rendering Index (CRI)	Ra75-85	Ra75-85	Ra75-85	Ra75-85	Ra75-85
Working Enviornment	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%
Material	Aluminum Copper PC	Aluminum Copper PC	Aluminum Copper PC	Aluminum Copper PC	Aluminum Copper PC
IP Rating	IP65	IP65	IP65	IP65	IP65
Working Life (Hours)	>50000	>50000	>50000	>50000	>50000
Product Dimension (mm)	60°: Φ390×280 120°: Φ415×356 150°: Φ580×280	60°: Φ480×525 120°: Φ580×415 150°: Φ580×320	60°: Φ480×525 120°: Φ580×415 150°: Φ580×320	60°: Φ480×565 120°: Φ580×455 150°: Φ580×360	60°: Φ480×565 120°: Φ580×455 150°: Φ580×360
Packing Dimension (mm)	Lamp Body 3kg/unit 2pcs/carton Reflector: 30pcs/carton 610×290×289	Lamp Body 5.5kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×429	Lamp Body 5.9kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×429	Lamp Body 7.2kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×610	Lamp Body 7.5kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×610
Net Weight/ Gross Weight (Kgs)	3kg/ 3.5kg	5.5kg 6kg	5.9kg 6.5kg	7.2kg 8k	7.5kg 8kg

Pure White LED High Bay Fixtures

It is applicable to large factory and workshop, office, storehouse, large superstore, supermarket, specialty stores, wholesale market and other places require high power lighting.

Pure White LED High Bay Fixtures

Tag:

Certification:	CE/ CSA/ SAA/ETL/ UL(Pending）.
Model Number:	AMB-3L-250W

Minimum Order Quantity:	2pcs
Price:	Negotiate
Packaging Details:	2pcs/carton
Delivery Time:	3days for samples, 7~15days for large quantity
Payment Terms:	TT, Western Union, L/C
Supply Ability:	5000pcs per month
