Detail Information

Color:	Black And Silver	IP Rate:	Ip65
Heat Sink:	Pure Copper Endothermic Material	Heat Sink2:	6063 Aluminum Heat Dissipation
Adjustable Angle:	60/120/150 Degree	Warranty Time:	5 Years
Highlight:	low energy high bay lighting , led high bay lamps

Product Description

Dimmable Driver High Bay Lighting Led 250 W IP65 UL TUV Bridgelux led

AMB led high bay advantages:

1. 3-5years warranty time, longer than most other suppliers.

2. Meanwell driver, which is top quality from TaiWan. It has UL, CE, TUV,PSE certificates.

3. Bridgelux 45mi C0B LED , it has 115-120lumens/w. 5years warranty time item is 130-145lumen/w with 6

0mil Bridgelux led chip.

4. Own cooling system. with our patent system, our LED's working temperature is only 50degrees when ambient temperature is 30-35degrees. much better than most others.

5. Different beam angles. we have 60degrees, 120degrees and 150degrees, it fits our clients different tastes.

Why choose our AMB led high bay light?

1. High brightness led high bay, original 60mil Bridgelux chip, which is 5 years warranty time.
2. High efficency and power factor driver, Taiwan Meanwell HLG driver.
3. Patent copper cooling system, this ideal heat dissipation design solve the heat problem 100%.
4. Long life-span, more than 5000hrs, our led high bay working temperature is only 48degree(tested in 34degree workshop).

250W LED High Bay Specifications:

Model No.	AMB-3L-250w
Equivalent	800~900W High Pressure Sodium Lamp
LED Light Source	3 × 70W Bridgelux 60mil LED
LED Luminous Efficiency	110 lm/w
Lamp Total Power	250W
Power Efficiency	> 95%
Lamp Rated Luminous Flux	287500-30000lm
Lamp Rated Luminous Efficiency	> 95lm/W
Color Rendering Index(CRI)	RA75-RA90
Color Temperature(Color Temperature)	Cool white: 6000-6500K
	Pure white: 5000-5500K
	Warm white: 2700-3200K
Beam Angle	60 degrees or 120 degrees or 150 degrees
Light Distribution/Beam Pattern	Round Beam
Input Voltage	AC 95-265V; DC 30-36V
FrequencyRange	50/60HZ
Power Factor(PF)	> 0.95
Total Harmonic Distortion(THD)	< 15%
Storage Temperature	-40--+80
Working Environment	-40--+50; 10%-95%RH
Junction Temperature(Tj)	60 ± 10%(ta=25)
Light Body and Lampshade Material	Aluminum Alloy and AL glass
Working Lifetime	> 80, 000hrs
IP Rating	IP65

Dimmable Driver High Bay Lighting Led 250 W IP65 UL TUV Bridgelux led

Application:

It is applicable to large factory and workshop, office, storehouse, large superstore, supermarket, specialty store, wholesale market and other places require high power lighting.

Tag:

Certification:	CE UL FC TUV ETL LM79 RoHS
Model Number:	AMB-3L-250W

Minimum Order Quantity:	2pcs
Price:	Negotiate
Packaging Details:	1PCS/BOX 2boxes/Carton 700355455mm
Delivery Time:	3days for samples, 7~15days for large quantity
Payment Terms:	TT, Western Union, L/C
Supply Ability:	10000pcs per month
